★ Low noise, high torque, and long-life performance.
★ Motor Voltage Range: 3V - 24V DC.
★ Dimensions: Diameter 27.7mm, Length 47mm.
★ Shaft Diameter: 2.3mm.
★ Output Power: Approximately 1W ~ 35W.
★ Direction of Rotation: CW (Clockwise) & CCW (Counter-Clockwise).
★ Construction: Carbon-brush permanent magnet motor.
★ Typical Applications: Massagers, vibrators, and air compressors.
Frequently Asked Questions
What is the voltage range for the RS-395 motor?
The typical operating voltage for these micro DC motors ranges from 3V to 24V, making them versatile for various power supplies.
What are the primary applications for this motor?
It is widely used in household appliances, including massagers, vibrators, air compressors, fans, and electric toys.
Is the motor shaft customizable?
Yes, both the motor specifications and the shaft length can be tailor-made according to specific customer requirements.
Does this motor support bidirectional rotation?
Yes, the RS-395 series supports both CW (Clockwise) and CCW (Counter-Clockwise) rotation directions.
What certifications do these products carry?
Our products are manufactured under strict quality standards and carry ROHS, CE, and ISO9001 certifications.
What is the expected delivery time for orders?
For standard orders, the delivery time is generally less than 30 days depending on the quantity and customization needs.
